你将学到什么
你将学到使用arduino控制一个8X8的LED矩阵
视频内容
视频若不清晰，1080P视频地址：
https://v.qq.com/x/page/g05583pt7gq.html?
文字代码如下：
//We always have to include the library
#include “LedControl.h”
/*
Now we need a LedControl to work with.
***** These pin numbers will probably not work with your hardware *****
pin 12 is connected to the DataIn
pin 11 is connected to the CLK
pin 10 is connected to LOAD/CS
We have only a single MAX72XX.
*/
LedControl lc=LedControl(12,11,10,1);
void setup() {
// put your setup code here, to run once:
/*
The MAX72XX is in power-saving mode on startup,
we have to do a wakeup call
*/
lc.shutdown(0,false);
/* Set the brightness to a medium values */
lc.setIntensity(0,8);
/* and clear the display */
lc.clearDisplay(0);
}
void loop() {
// put your main code here, to run repeatedly:
byte eight[8]= {0x7E,0x7E,0×66,0x7E,0x7E,0×66,0x7E,0x7E}; //8
byte smeil[8]={
B00111100,
B01000010,
B10100101,
B10000001,
B10100101,
B10011001,
B01000010,
B00111100
};
for(int i=0;i<8;i++)
{
lc.setRow(0,i,eight[i]);
}
delay(1000);
lc.clearDisplay(0);
for(int i=0;i<8;i++)
{
lc.setColumn(0,i,eight[i]);
}
delay(1000);
lc.clearDisplay(0);
for(int i=0;i<8;i++)
{
lc.setRow(0,i,smeil[i]);
}
delay(1000);
lc.clearDisplay(0);
for(int row=0;row<8;row++)//行
{
for(int col=0;col<8;col++)
{
lc.setLed(0,row,col,true);
delay(100);
}
}
}
